Parallel and Distributed Processing with 'rgeomorphon'

library(rgeomorphon)

When working with large Digital Elevation Models (DEMs), calculating geomorphons can be time-consuming. rgeomorphon can speed up this process by using parallel and distributed processing. This vignette explains how to set up and use the tiling and parallel processing features of the package.

Working with Tiles

Parallel processing in rgeomorphon is achieved by splitting the input raster into smaller tiles. Each tile is then processed independently on a separate worker. The results are then combined back into a single, seamless raster.

The number of tiles is estimated using terra::mem_info() to identify raster memory requirements, amount of free memory, fraction of memory that can be used by terra, number of “copies” of the input data raster needed to complete processing, etc.

The tiled approach is used automatically when a raster is too large to fit in memory. However, you can either directly set the number of chunks to use, or set other factors related to relative memory usage constraints.

The Parallel Ecosystem

Two Layers of Parallelism

rgeomorphon offers two distinct layers of parallelism to accelerate calculations. This parallelism allows rgeomorphon to perform optimally across a range of hardware, from a personal laptop to a high-performance computing (HPC) cluster.

RcppParallel speeds up the work inside each tile, while packages from the futureverse allow you to distribute the processing of multiple tiles across multiple R sessions.

Low-Level Parallelism (within a single chunk): At its core, rgeomorphon uses RcppParallel to execute the main geomorphon algorithm in C++. This provides efficient, multi-threaded computation on a single data chunk. When you run geomorphons() on a raster that fits in memory, RcppParallel will automatically attempt to use multiple CPU cores to speed up the calculation. This is a form of shared-memory parallelism that works “out of the box.”
High-Level Parallelism (across multiple chunks): For rasters that are too large to fit in memory, rgeomorphon divides the data into smaller, independent tiles. You can control how these independent tiles are processed by providing a parallel lapply-like function to the LAPPLY.FUN argument. A great option for this is future.apply::future.lapply(). There are two key steps to setting up your R session:
Set a future plan: This tells R how to distribute the tiles. For example, plan(multisession) tells future to use separate R sessions on your local machine.
Provide a parallel lapply function: You need to pass a parallel-aware loop function to geomorphons() via the LAPPLY.FUN argument.

Scaling Up: From a Laptop to a Cluster

The only piece of code you need to change to switch between different parallel strategies is the future::plan(). This single command configures the entire backend. Let’s look at a few common scenarios.

Scenario 1: Sequential Processing (No Parallelism)

To disable all high-level parallelism and process tiles one-by-one in your main R session, you use plan(sequential). This is great for debugging or for situations where the overhead of parallelism isn’t worth it.

library(future)

# Process everything in the current R session, one tile after another.
plan(sequential)

Scenario 2: Local Multicore Processing

Local processing using multiple R sessions is the most common scenario for users with a modern multi-core laptop or workstation. plan(multisession) starts several new, independent R sessions in the background on your local machine. Each session will work on a different tile of the raster.

# Use 4 background R sessions on this computer
future::plan(multisession, workers = 4)

On this backend, the low-level RcppParallel engine within each worker will still try to use multiple threads, so they will be competing for the same CPU cores. Even so, this is a simple and effective way to parallelize on a single machine.

Scenario 3: Distributed Cluster Processing

If you have access to a High-Performance Computing (HPC) cluster or several machines on a network, you can use the cluster backend. The future framework will handle the logistics of sending individual tiles to different machines for processing.

# Distribute work to two specific machines on the local network
future::plan(cluster, workers = c("machine1.local", "machine2.local"))

In this setup, rgeomorphon will send a tile to machine1.local. Once it arrives, the RcppParallel engine on machine1.local will take over and use all of its local cores to process that tile as fast as possible. This allows you to scale your processing power far beyond the limits of a single computer.

The `geomorphons()` Call Stays the Same

Regardless of which of the backends you configure with future::plan(), your call to geomorphons() remains identical.

g_forms <- geomorphons(
    my_large_dem,
    search = 50,
    LAPPLY.FUN = function(X, FUN, ...) {
        future.apply::future_lapply(X, FUN, future.seed = TRUE, ...)
    }
)

# Remember to always return to a sequential plan to shut down workers
plan(sequential)

To learn more about the different future backends and their configuration options (including for job schedulers like Slurm or TORQUE), we highly recommend exploring the documentation and vignettes on the official future package website.

Demo with `salton`

Let’s demonstrate this with the salton dataset included with rgeomorphon. This dataset is small and would not normally trigger tiled processing.

library(rgeomorphon)
library(terra)

## terra 1.8.60

library(future)
library(future.apply)

# Load the salton dataset and prepare it as a SpatRaster
data("salton", package = "rgeomorphon")
dem <- terra::rast(salton)
names(dem) <- "Elevation"
crs(dem) <- attr(salton, "crs")
ext(dem) <- attr(salton, "extent")

# By default, this small raster is processed in a single chunk
geomorphon_chunks_needed(dem)

## [1] 1

To force tiled processing we can manipulate the environment variables that rgeomorphon uses to estimate memory needs. We will set R_RGEOMORPHON_MEM_SCALE_NEED to tell the function how much memory the processing of the input raster will need. This scaling factor is the number of equivalent “copies” of the input data you need to process it.

# Scale up the memory needed (equivalent to number of input raster copies)
Sys.setenv(R_RGEOMORPHON_MEM_SCALE_NEED = 1e7)

# which will cause the chunking algorithm to divide the raster
geomorphon_chunks_needed(dem)

## [1] 17

# Unset the environment variable
Sys.unsetenv("R_RGEOMORPHON_MEM_SCALE_NEED")

We can also pass the nchunk argument directly to geomorphons() to bypass the memory-based heuristics.

Now that geomorphons() will use a tiled approach, we can set up our parallel plan and execute the calculation.

# Set up a multisession future plan with 4 workers
# This creates 4 background R sessions to do the work
future::plan(multisession, workers = 4)

Use the LAPPLY.FUN argument to pass future.apply::future_lapply. This tells geomorphons() to use the future backend for processing tiles

system.time({
    g_parallel <- geomorphons(
        dem,
        search = 10,
        flat = 0.1,
        LAPPLY.FUN = function(X, FUN, ...) {
            future.apply::future_lapply(X, FUN, future.seed = TRUE, ...)
        },
        nchunk = 2
    )
})

##    user  system elapsed
##   1.748   0.282  13.401

# Shut down the parallel workers
future::plan(sequential)

# Inspect
terra::plot(g_parallel, main = "Geomorphons via Tiled Processing")

Important Notes

Overhead: For small datasets like salton, the overhead of setting up parallel sessions and tiling the data will make the process slower than a simple sequential calculation. The benefits of parallel processing become apparent with larger rasters.
future.seed = TRUE: Using future.seed = TRUE is highly recommended to ensure that any random number generation is handled properly across the parallel sessions, making your results reproducible.
Backend Flexibility: The future package allows for many different parallel backends. The geomorphons() code remains exactly the same.

Beyond Parallelism: The Flexibility of `LAPPLY.FUN`

While future.apply::future_lapply is the recommended way to achieve scalable, high-level parallelism, the LAPPLY.FUN argument is intentionally designed as a generic interface. It is not locked into the futureverse ecosystem. You can provide any R function that behaves like base::lapply(), giving you control over how tiles are processed.

This hook makes the tile-processing loop customizable, allowing for logging, error handling, or integration with virtually any sequential or parallel looping mechanism in R.

For example:

Using Alternative Parallel Backends: If you prefer a different parallel framework, such as the one provided by the base parallel package, you can easily integrate it.

# Example using the base R parallel package
library(parallel)
cl <- makeCluster(4)

g_forms_par <- geomorphons(
    dem,
    search = 10,
    flat = 0.1,
    LAPPLY.FUN = function(X, FUN, ...) {
        parLapply(cl, X, FUN, ...)
    }
)

stopCluster(cl)

Injecting Progress Reporting and Logging: For very large datasets, processing can take a long time. You can use LAPPLY.FUN to create a wrapper function that provides real-time feedback or writes to a log file as each tile is completed. This doesn’t require any parallel backend; it simply modifies the loop’s behavior.

In the example below, we create a custom function that prints a message before and after processing each tile. Tiles are processed sequentially with base::lapply()
```
# Define a custom lapply-like function that adds reporting
reporting_lapply <- function(X, FUN, ...) {

    reporting_FUN <- function(i) {
        message(paste0("Starting tile #", i, " at ", Sys.time()))
        result <- FUN(i, ...)
        message(paste0("Finished tile #", i, " at ", Sys.time()))
        return(result)
    }

    lapply(X, reporting_FUN)
}

g_forms_reported <- geomorphons(
    dem,
    search = 10,
    flat = 0.1,
    LAPPLY.FUN = reporting_lapply
)
```
This prints a start and end message to the console for every tile processed, giving you a live view of the progress.
